FSP DAGGER PRO ATX3.0(PCIe5.0) 850W power supply unit 20+4 pin ATX SFX Black
kr1,615.00
Tax included
FSP DAGGER PRO ATX3.0(PCIe5.0) 850W, 850 W, 100 - 240 V, 50/60 Hz, 12-6 A, Active, 120 W
FSP DAGGER PRO ATX3.0(PCIe5.0) 850W. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 13.8" (35 cm), SATA power cable length: 450 mm. Purpose: PC, Power supply unit (PSU) form factor: SFX, 80 PLUS certification: 80 PLUS Gold. Product color: Black, Cooling type: Active, Fan diameter: 3.62" (9.2 cm). Cables included: CPU, PCIe, Peripheral (Molex), SATA
| Total power | 850 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 12-6 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 850 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 70.83 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Efficiency | 90% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit |
| Motherboard power connector | 20+4 pin ATX |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Motherboard power cable length | 13.8" (35 cm) |
| Number of SATA power connectors | 6 |
| SATA power cable length | 450 mm |
| PCI Express power connectors (6+2 pin) | 2 |
| PCI Express power connectors (12+4 pin) | 1 |
| PCI Express power connectors (12+4 pin) cable length | 500 mm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 17.7" (45 cm) |
| Cabling type | Fully-Modular |
| Purpose | PC |
| Power supply unit (PSU) form factor | SFX |
| 80 PLUS certification | 80 PLUS Gold |
| ATX version | 3.0 |
| Bearing technology | Ball bearing |
| Product color | Black |
| Cooling type | Active |
| Fan diameter | 3.62" (9.2 cm) |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| On/off switch | Yes |
| Cables included | CPU, PCIe, Peripheral (Molex), SATA |
| Width | 3.94" (100 mm) |
| Depth | 4.92" (125 mm) |
| Height | 2.5" (63.5 mm) |
PPA8503900
1 Item
Data sheet
- Product color
- Black
- Width
- 3.94" (100 mm)
- Depth
- 4.92" (125 mm)
- Height
- 2.5" (63.5 mm)
- Cables included
- CPU, PCIe, Peripheral (Molex), SATA
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
- On/off switch
- Yes
- Purpose
- PC
- Input current
- 12-6 A
- Number of fans
- 1 fan(s)
- Power protection features
- Over current, Over power, Over voltage, Overheating, Short circuit
- Cooling type
- Active
- 80 PLUS certification
- 80 PLUS Gold
- Efficiency
- 90%
- Fan diameter
- 3.62" (9.2 cm)
- Peripheral (Molex) power connectors (4-pin)
- 2
- Total power
- 850 W
- Max output current (+12V)
- 70.83 A
- Max output current (+5Vsb)
- 2.5 A
- Motherboard power connector
- 20+4 pin ATX
- Number of SATA power connectors
- 6
- PCI Express power connectors (6+2 pin)
- 2
- CPU power connector (4+4 pin)
- Yes
- Cabling type
- Fully-Modular
- Power supply unit (PSU) form factor
- SFX
- Bearing technology
- Ball bearing
- Power Factor Correction (PFC) type
- Active
- Combined power (+3.3V)
- 120 W
- Combined power (+12V)
- 850 W
- Combined power (+5V)
- 120 W
- Max output current (+3.3V)
- 20 A
- Max output current (+5V)
- 20 A
- Max output current (-12V)
- 0.3 A
- Motherboard power cable length
- 13.8" (35 cm)
- PCI Express power connectors (12+4 pin)
- 1
- Combined power (-12V)
- 3.6 W
- Combined power (+5Vsb)
- 12.5 W
- SATA power cable length
- 450 mm
- PCI Express power connectors (12+4 pin) cable length
- 500 mm
- CPU power cable length
- 17.7" (45 cm)
- ATX version
- 3.0
- Fan location
- Top
